Sealing system of oil cylinder products adopts NOK, Trelleborg, Parker and other brand seals. The unique sealing combination verified by the market for many years, with reliable sealing and long service life.
Cylinder diameter: 50-450mm
Rod diameter: 30-700mm
Stroke: 200-9500mm
Operating pressure: 18-40Mpa
Push-pull force: 0-5560KN
Operating temp.: -40-120℃
Consultation hotline
4009995318Product Advantages
Our hydraulic cylinder products feature a sealing system selected from renowned brands such as NOK, Trelleborg, and Parker. Utilizing a unique combination of seals validated by years of market experience, our seals ensure reliability and long service life. The piston rod undergoes advanced processes such as friction welding, high-frequency quenching, and nickel-chromium composite plating/laser cladding to enhance wear resistance, impact resistance, fatigue resistance, and corrosion resistance, thereby extending product lifespan. The cylinder tube is made of high-strength materials developed in collaboration with steel mills, meeting requirements for low temperature and fatigue. Developed using bore roller pressing technology, the cylinder tube ensures surface roughness and dimensional accuracy of the inner bore, enhancing product reliability, low-temperature resistance, and smooth operation at low speeds. Our products undergo online automatic flaw detection, online three-coordinate and optical dimension inspection, and recording, ensuring product quality and traceability. With capabilities for pulse, tension, offset load, high-frequency reciprocation, buffering, high and low temperature, and environmental cylinder testing we confidently guarantee product reliability.
Technical Parameter
| Technical parameters | |||||||
| Product model | Dimensions in mm | Working pressure Mpa | Push-pull force KN | Operating temperature °C | |||
| Bore | Rod diameter | itinerary | |||||
| Pump truck oil cylinder | 50-450 | 32-280 | 200-8000 | 35 Mpa | 5560 | 3000 | -40～120 |
| Excavator oil cylinder | 50-300 | 30-200 | ≤3500 | 35 | ≤250 | ≤200 | -40～120 |
| Crane oil cylinder | 80-100 | 79-700 | 1600-6400 | 25-40 | 125-31500 | 30-1400 | -40～120 |
| Piling machinery oil cylinder | 125-180 | 90-125 | 4300-6050 | 25-35 | 300-890 | 145-460 | -40～120 |
| Mineral truck oil cylinder | 160 | 120 | 200 | 25 | 502 | / | -40～120 |
| Boring machinery oil cylinder | 100 | 63 | 550 | 25 | 196 | 118 | -40～120 |
| Grader oil cylinder | 80-90 | 50-55 | 1012-1242 | 18 | 90-115 | 55-72 | -40～120 |
| Paver cylinders | 115-145 | 110-140 | 600-750 | / | / | / | |
| Port machinery oil cylinder | 100- 180 | 90- 160 | 800- 9500 | ≤30 | 160-600 | 0 | -40～120 |
